G-LOADER ADV
Power Up Productivity with G-Loader.
Looking for an efficient solution to simplify fabric roll loading while reducing time, cost, and manual effort? The G-LOADER ADV is engineered for modern production environments, delivering fast, and fully automated fabric handling.
Built with a robust structure and ergonomic design, it enhances workflow efficiency while ensuring operator comfort. The multi-roll loading system optimizes material handling, minimizes fabric damage, reduces labour dependency, and significantly improves productivity.
HMI Touchscreen
PLC Automation
Servo Positioning
Multi-Width Compatibility
Features
- User-Friendly Touchscreen HMI with Customizable Settings
- PLC-Based Automation Control System
- High-Efficiency Automatic Fabric Loading to Spreader/G-RELAX/Cutter
- High-Capacity Roll Lifting Arm
- Servo-Controlled Precision Positioning
- Precision Linear Motion System
- Adjustable Roll Diameter & Multi-Width Compatibility
- Modular Inline Integration Design
- Heavy-Duty Structural Frame with Stable Anti-Vibration Base
- Real-Time Monitoring System
- Advanced Safety Mechanisms
Technical Specifications
| Specifications | G-LOADER ADV 180 | G-LOADER ADV 200 | G-LOADER ADV 220 |
|---|---|---|---|
| Machine Model | # GLA-70-100-00 | # GLA-78-100-00 | # GLA-86-100-00 |
| Power Supply | 230V ±10V AC (single phase), 50/60 Hz, 32 Amps | 230V ±10V AC (single phase), 50/60 Hz, 32 Amps | 230V ±10V AC (single phase), 50/60 Hz, 32 Amps |
| Power Consumption | 2.5 kW | 2.5 kW | 2.5 kW |
| Dimensions (L X W X H in mm) | 2650 x 700 x 2450 | 2850 x 700 x 2450 | 3050 x 700 x 2450 |
| Weight | 480 kg | 495 kg | 510 kg |
| Load Capacity | 100 kg | 100 kg | 100 kg |
| Operating Temperature Range | 25°C - 58°C | 25°C - 58°C | 25°C - 58°C |
